The MeltPrep Slider
Faster Process Development for your Formulation
To begin prototyping with Vacuum Compression Molding technology, the only process parameter you need is the process temperature. Now, with our innovative MeltPrep Slider, you can effortlessly determine this key parameter in no time – no matter if it’s a pure substance or formulation.​
Detect Process Temperature Effortlessly with the MeltPrep Slider
Using the MeltPrep Slider is easy! Simply turn on the tool, wait for it to reach full heat, place your material on the Glass Slide, and gently slide it over the instrument. As the material begins to soften, you can visually detect the transition into a viscous liquid—no additional calibration is needed. Once you've identified this key parameter, you'll have the precise temperature needed to set the heating unit for the VCM process.
MeltPrep Slider Features & Innovations
All Temperatures Available
All temperatures within the 50 °C to 300 °C range are always ready for immediate use without delays.
No Calibration Required
An internal temperature controller maintains a consistent linear gradient, removing the need for manual calibration.
Glass Slide for Easy Handling
The MeltPrep Slider uses a small glass plate to hold your material, making it easy to slide across the temperature scale for accurate readings.
Compact & Portable Design
The MeltPrep Slider is built for easy portability with its small footprint allowing for convenient testing anywhere.​​
No Cleaning of Hot Surfaces
Because the material is placed on the Glass Slide, there’s no need to clean the heated device between measurements—simply replace the slide and clean it once it has cooled.
MeltPrep Slider for Easy VCM Process Viscosity Estimation
The MeltPrep Slider simplifies estimating whether your material's viscosity is suitable for the VCM process. Start by determining the softening point of your material and allowing it to soften. Once softened, flip the Glass Slide with the material upright. If the material stays on the Glass Slide without sliding off, the viscosity is ideal for the VCM process.
See & Feel Your Material's Viscosity
Easily observe the viscosity of your material with a simple, hands-on approach. Use a spatula to scrape the softened material along a glass slide. The combination of visual cues and tactile feedback makes estimating viscosity quick and straightforward.
How the MeltPrep Slider Works
The MeltPrep Slider is equipped with an elongated heating surface that, due to its innovative design, creates a linear temperature gradient, ranging from 50 °C at the coolest end to 300 °C at the hottest. Temperature indicators allow you to easily identify the temperature for each position on the heating surface visually without the need for any additional tools.
Speed Up Your Formulation Development Process Today!
Accelerate up your formulation development process with the MeltPrep Slider, designed to streamline your work with precision and efficiency. Contact our experts today or book a free demo to see how the MeltPrep Slider can enhance your workflow and achieve faster results. Don’t miss this opportunity to take your formulations to the next level!
